The Icicle Atlas
|
Run date: | 2011-08-17 |
Wall temperature: | -13.62 C |
Air temperature: | -10.87 C |
Water flow rate: | 2.3582 g/min |
Water type: | Canadian Springs (TM) distilled water |
Salt concentration: | no added salt |
Surfactant concentration: | no added surfactant |
Input nozzle temperature: | 2.96 C |
Fan flux: | 0.95 m^3/min per fan |
Support rotation: | Rotating support |
Support rotation rate: | 4.05 min/rot |
Relative humidity: | 87.1 % |
Scale of raw images: | 54.160 pixel/cm |
