The Icicle Atlas
|
Run date: | 2012-09-19 |
Wall temperature: | -14.92 C |
Air temperature: | -12.26 C |
Water flow rate: | 1.2363 g/min |
Water type: | Canadian Springs (TM) distilled water |
Salt concentration: | 3.20e-02 wt % |
Surfactant concentration: | 2.50e-03 wt % of Triton X-100 |
Input nozzle temperature: | 2.14 C |
Fan flux: | 1.05 m^3/min per fan |
Support rotation: | Rotating support |
Support rotation rate: | 4.06 min/rot |
Relative humidity: | 85.1 % |
Scale of raw images: | 53.488 pixel/cm |
